21 NOVEMBER 2009
DIY CNC Mill Controller for Stepper Motor Milling Machine
This addon to our CNC mill was made to allow manual control of the mills cnc stepper motors using a pair of 2 axis joysticks obtained from a broken radio control...
26 OCTOBER 2009
DIY Camera Laser Break Beam Trigger MK 2
A DIY optical camera flash or camera trigger using a laser and PIC Processor based timer circuit.
Following from the basic high speed photography trigger we made, we found that...
18 OCTOBER 2009
A DIY optical camera flash or camera trigger using a laser and basic timer circuit.
I have always enjoyed trying to take water drop photos but getting the flash and camera to trigger at the right moment by hand was always...
11 OCTOBER 2009
My new Mac Pro tower has had an annoying high pitched squeal or whine when moving windows or scrolling windows on the screen.
The sound is not there all the time but only after the machine has been on for a few hours...
29 SEPTEMBER 2009
DIY wall for Chromakey green screen recording.
After spending a lot of time trying to get good quality green screen footage for e-learning projects using cloth backgrounds, we decided to build a dedicated wall at the studio...
27 JUNE 2009
After looking for more items around the house which could be charged from the new solar system, we decided to try converting the Logitech Harmony 885 remote control chargers to run from 12 volts.
The Logitech charger runs...
26 JUNE 2009
After moving my monitors around on the office desk to make way for some new kit, I found that the best place would be if one of the screens was fitted flush against one of the brick walls in the office.
I made this VESA...
02 JUNE 2009
Putting it all together
Built the first of four panels today and got it installed on the roof. I am still waiting for the 12v 15amp cable roll for the other three panels, which I ordered over a week ago and the supplier...
01 JUNE 2009
Soldering Cells
After purchasing a flux pen from Maplin, we started the long job of tinning all the cells, front and back and the fitting the tabbing wire between the cells to join 36 together for each solar panel.
The...
28 MAY 2009
Charging System Upgrades
The existing charging system used a single battery and this was connected via the charge converter to the inverter and a 12v relay which switched the mains supply between the solar inverter power...
24 MAY 2009
Using 6mm thick flat aluminum bar, we made four brackets which were attached to the chimneys either side of the house and between these, two lengths of 25mm x 4.2m square aluminum bar were fitted to act as supports for the...
19 MAY 2009
Using 35mm square aluminum bar, we machined a slot into the bar and cut it into 30mm wide brackets which where drilled and tapped to take M5 bolts. Four of these brackets will be bolted to the panel base boards and this will...
10 MAY 2009
Two coats today of Dulux Trade Weathershield Preservative Basecoat to seal the wood, this needs 48 hours to dry and then the panels will be painted with exterior gloss and the glass ordered.
The photo below shows the panels...
09 MAY 2009
After purchasing further solar cells from the USA via ebay, We are building four new weather proof outdoor solar panels which should supply around 320w which should be enough energy to run the household lighting circuit and...
07 MAY 2009
I have added a new custom gallery to the blog which you can access via the Gallery link on the top of each page or on https://www.briandorey.com/gallery/
22 FEBRUARY 2009
Went out for a drive today with my Canon Eos 5D in the car and did one frame every second which was then converted into a time lapse movie
http://vimeo.com/moogaloop.swf?clip_id=3321437
